The fully automatic brick making machine is a high-quality machine that produces top-notch bricks and paver blocks without any manual intervention. The entire production process is seamlessly automated and supervised by a PLC Unit, making these machines necessary in today's brick making industry.
This fully automatic brick machine offers easy operations and requires minimum maintenance. They are highly appreciated for their durability, efficiency, and cost-effectiveness.
Automatic brick making machines are widely used in the construction industry to produce hollow blocks, solid blocks, concrete bricks, color pavers, interlocking pavers, paving blocks, and other concrete blocks. These machines are designed by a team of experienced professionals, who have years of experience in their domain. Featuring a hydraulic system and an electric control panel, this machine serves as a vital tool across multiple sectors, including the building construction industry, Road Development projects, Government initiatives, and industrial brick making enterprises.
There are various categories of Fully Automatic brick making machines, each with its unique features and capabilities. Let's delve into more information and valuable advice for selecting the best Fully Automatic brick making machine for your needs.
10.2 Fully automatic machine: This remarkable machine can operate non-stop, 24 hours a day. Its exceptional speed and advanced servo motors enable high production capacity. With the flexibility to switch molds, the machine can create a range of products, including Concrete Paving Blocks, Hollow Blocks, Insulated Bricks, Different Curbstones, Asmolen, and Chimney Blocks, with heights ranging from 2cm to 40cm. In an 8-hour shift, it can produce 700 m² of Paving Blocks or 10,000 pieces of Concrete Hollow Blocks.
We are Producing this Fully Automatic Brick Machine in various ranges, sizes, and designs to serve our clients as per their requirements. Besides this, our products are dispatched to the market after being examined by our quality controllers team.
These machines also have an automatic version as well for smaller businesses. For more details, you can see Automatic Brick Making Machine.
Fully Automatic Brick Making Machine Video
This video shows the efficient production of interlock paver bricks using an automatic brick machine. The machine's operation is so streamlined that only three personnel are required to operate it effectively. In this specific case, the machine has been successfully installed in Georgia for a valued customer. The video not only demonstrates the machine in action but also highlights the crucial training provided to the customer's staff for seamless utilization.
For more details about our machines, you can contact us directly by sending emails or contacting us by Whatsapp, also you can visit Vess youtube channel for more brick making machine videos.
The Advantages of Fully Automatic Brick Making Machine
►A high degree of automation
PLC electric control system is applied to the machine, and it fully controls all the procedures. The advanced fault diagnosis device will check and correct the errors automatically.
►Easy operation
It adopts the inverter control stacker system, which ensures smooth and secure running. All the production processes, from feeding to stacking, are completed by the fully automatic production line control system.
►Low energy consumption
when the automatic brick machine comes into operation, the host machine is running all the time. While other engines run intermittently. The intermittent running ensures low energy consumption.
►Thermal Treatment
The machine adopts a heavy-duty design and high-strength steel materials with advanced thermal treatment. The whole machine and the molds are hard-wearing. The advanced technology applied to the machines prolongs the service life.
The Technical Specification Of Fully Automatic Brick Making Machine
Before buying or choosing any kind of brick making machine you need to consider the quality of the machine then the price. The price of the automatic brick making machine is offered as a complete plant “Turnkey Project”. Except for product drying and curing rooms, there is no extra equipment needed in the plant area.
For a plant of these features the recommended installation, curing, and stock area is a minimum of 3.000 m2. There is no obligation for roofing. The prepared concrete floor should be a minimum of 1/3 of the plant area.
| TECHNICAL DETAILS | |||
|---|---|---|---|
| Mortar Hoppers And Capacity | Double Hopper / 1 m³ | Upper Vibrator Motor Power | 0,50 Kw x 2 Pieces |
| Control System | Fully Automatic | Hydraulic Motor Power | 38 Kw |
| Production Capacity | 100-120 Pallets / Hour | Hydraulic Oil Tank Capacity | 200 Lt |
| Weight | 11.000 Kg | Hydarulic Pressure | 200 Bar |
| Machine Dimensions | 220 cm / 750 cm / 250 cm | Vibration Cooling Capacity | 22.000 Kcal |
| External Chassis Dimensions | 150 x 200 x 6 mm Closed Profile | Total Power Usage | 54 Kw |
| Vibration Force | 42.500 Kg | Min - Max Product Height | 2-40 cm |
| Lower Vibrator Motor Power | 7.5 Kw x 2 Pieces | Wooden Pallet Dimensions | 95 x 120 x 5 cm |
| CAPACITY INFORMATION | ||
|---|---|---|
| PRODUCT TYPE | NUMBER OF PRODUCTS ON PALLET | DAILY PRODUCTION CAPACITY (8 HOURS) |
| Hollow Block 100 X 400 X 200 | 18 | 18.000 |
| Hollow Block 150 X 400 X 200 | 12 | 12.000 |
| Hollow Block 200 X 400 X 200 | 10 | 10.000 |
| Asmolen 250 X 400 X 200 | 8 | 8.000 |
| CAPACITY INFORMATION | ||
|---|---|---|
| PRODUCT TYPE | NUMBER OF PRODUCTS ON PALLET | DAILY PRODUCTION CAPACITY (8 HOURS) |
| Interlocking Paving Block | 25 | 700 m² |
| Rotary Paving Block | 25 | 700 m² |
| Rectangular Paving Block | 40 | 800 m² |
| Curbstone 150 x 700 x 300 | 3 | 2.900 Pieces |
Fully Automatic Machine Price and Contact Information:
With more than 15 Years of experience in the production of automatic brick making machines, contact us for factory direct sales and prices. According to your need, in an automatic brick production plant, you can replace the mold for the machine to produce different kinds of cement bricks. Vess has rich experience in manufacturing brick making machines, cement brick machines, and other types of block making machines. We provide full production line solutions and support for customers to start a brick production business, We prepare full project support from custom design to installation and free training, after-sale support, and in the future upgradeability opportunity.
| FULLY-AUTOMATIC BRICK MAKING MACHINE TYPES AND PRICE | PRICE ACCORDING TO PRODUCTION CAPACITY |
|---|---|
| ►10.1 - Daily 700 m² Paving Blocks AND 10.000 Pieces Hollow Blocks | Starts from 115.480 Euro |
| ►12.1 - Daily 1.000 m² Paving Blocks AND 12.000 Pieces Hollow Blocks | Starts from 135.480 Euro |
| ►15.1 - Daily 1.150 m² Paving Blocks AND 15.000 Pieces Hollow Blocks | Starts from 185480 Euro |
| ►18.1 - Daily 1.300 m² Paving Blocks AND 18.000 Pieces Hollow Blocks | Starts from 225480 Euro |
| ►24.1 - Daily 1.500 m² Paving Blocks AND 24.000 Pieces Hollow Blocks | Starts from 335480 Euro |
We also have lower capacity automatic block making machines with cheaper prices starting from 40.000 USD. You can also contact us if you have any further questions.
We also provide business plans based on your country and your favorite products in your market. Feel free to contact us anytime.
